Aeon Panacea Brushed Stainless Steel Radiator - 1000mm (w) x 620mm (h)
Product Code:
NWT1944-38140
Alluring, understated elegance. This low-slung louvre-style radiator sits unobtrusively against the wall, throwing out plenty of heat without feeling the need to shout about it.
Description
Why is an AEON Radiator the pinnacle of Sculptural Heating?
With a wealth of experience in the manufacture of reliable heating solutions the Aeon range takes this to a whole new level of unrivalled performance and beauty. The striking collection has been created, crafted and hand-finished by experts, using only the finest quality materials available.
"Panacea" Alluring, understated elegance. This low-slung louvre-style radiator sits unobtrusively against the wall, throwing out plenty of heat without feeling the need to shout about it.
Available Models:
Panacea 400mm(w) x 480mm(h) x 75mm(d) - (1147 BTUs / 10 Sections)
Panacea 500mm(w) x 480mm(h) x 75mm(d) - (1434 BTUs / 10 Sections)
Panacea 600mm(w) x 480mm(h) x 75mm(d) - (1721 BTUs / 10 Sections)
Panacea 700mm(w) x 480mm(h) x 75mm(d) - (2008 BTUs / 10 Sections)
Panacea 800mm(w) x 480mm(h) x 75mm(d) - (2295 BTUs / 10 Sections)
Panacea 900mm(w) x 480mm(h) x 75mm(d) - (2582 BTUs / 10 Sections)
Panacea 1500mm(w) x 480mm(h) x 75mm(d) - (4303 BTUs / 10 Sections)
Panacea 1600mm(w) x 480mm(h) x 75mm(d) - (4590 BTUs / 10 Sections)
Panacea 1000mm(w) x 620mm(h) x 75mm(d) - (3729 BTUs / 13 Sections)
Panacea 1200mm(w) x 620mm(h) x 75mm(d) - (4475 BTUs / 13 Sections)
Panacea 1400mm(w) x 620mm(h) x 75mm(d) - (5221 BTUs / 13 Sections)
Panacea 1600mm(w) x 620mm(h) x 75mm(d) - (5967 BTUs / 13 Sections)
Quality & Performance:
- Manufactured from 100% Stainless Steel.
- All products tested to EN442, the harmonised European Standard.
- Tested to 10 bar of Pressure.
- BTU heat outputs certified by HKL Laboratories of Stuttgart, Germany.
- High Quality Stainless Steel Grade 304
- BS Kitemark.
- 20 Year Manufacturer Guarantee.
- Standard 1/2" BSP threaded valve connections.
- Supplied with Brackets, Blanking Plugs, Airvents, Fixing Screws and Raw Plugs, Bleed Key.
Delivery:
- Your order will be delivered on a 2/3 day dedicated delivery service.
- All AEON stainless steel products boxed in specifically made wooden crates for additional safety during transportation.
Returns:
Please Note: Due to the bespoke nature of the AEON range of products any returns would be subject to a standard Restocking Fee.
Product Specifications
Everything you need to know about this product, from dimensions and installation to finish and performance.
Dimensions
Width (mm)
400mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1500mm, 1600mm
Height (mm)
480mm, 620mm
Depth (mm)
75mm
Projection
100mm to 115mm
Pipe Centres
Width of Radiator minus 20mm plus Valves
Socket Width
1/2" BSP
Technical Specifications
Output BTUs
1147, 1434, 1721, 2008, 2295, 2582, 3729, 4303, 4475, 4590, 5221, 5967
Output Watts
336, 420, 504, 588, 673, 757, 1093, 1261, 1311, 1345, 1530, 1749
Fuel Type
Central Heating
Materials & Construction
Material
Stainless Steel (Grade 304)
Design & Appearance
Design
Panacea
Outer Finish
Brushed Stainless Steel
Colour Family
Brushed Stainless
Tube Bar Pattern
See Description
Certifications & Standards
Guarantee
20 Years
Brand & Product Codes
Aeon Radiators
Files & Downloads
Installation guides, technical sheets and supporting product documents.
