Ultraheat "Linear" White Double Flat Panel Horizontal Radiators (13 Sizes)

NWT1979-38451
LD606W
star star star star star_outline
  • In Stock
  • Btus: 1476 - 9345
  • 433 - 2739 Watts
Ultraheat "Linear" Double White Horizontal Radiators
search
  • Ultraheat "Linear" Double White Horizontal Radiators

The slimline Linear double panel horizontal radiators fit seamlessly into a variety of roomsets in a gloss white finish. This contemporary radiator can be used throughout the home and will enhance any modern kitchen or living room. The range of available sizes makes this ideal for full house renovations.

Size
£157.00
VAT included
5% Checkout Discount on 3 or more Ultraheat Radiators or Towel Rails
local_shipping Order now for FREE delivery between Wednesday, 1st June - Thursday, 2nd June
On display in the showroom. This product is available to view in our Conwy based showroom.

Data sheet

Height (mm)
600mm
Width (mm)
321mm, 427mm, 533mm, 639mm, 745mm, 851mm, 957mm, 1063mm, 1222mm, 1434mm, 1646mm, 1858mm, 2017mm
Depth (mm)
61mm
Outer Finish
White Powder Coating
Material
Mild Steel
Design
Linear
Output BTUs
1476, 1967, 2459, 2951, 3443, 3935, 4427, 4918, 5656, 6640, 7624, 8607, 9345
Output Watts
433, 576, 721, 865, 1009, 1153, 1297, 1441, 1658, 1946, 2234, 2522, 2739
Tube Diameter (mm)
40mm Sections
Tube Bar Pattern
6, 8, 10, 12, 14, 16, 18, 20, 23, 27, 31, 35 or 38 - All x2 as Double Vertical Sections (See Widths)
Fixing Kit
4 Point Fixing Kit
Accessories
Supplied with Wall Brackets, Bleed Valve & Blank Plug
Guarantee
5 Years
Projection
97mm
Pipe Centres
Width of Radiator Plus Width of Valves
Socket Width
1/2" BSP
Fuel Type
Central Heating
Brand
Ultraheat Ultraheat

Downloads

The slimline Linear double panel horizontal radiators fit seamlessly into a variety of roomsets in a gloss white finish. This contemporary radiator can be used throughout the home and will enhance any modern kitchen or living room. The range of available sizes makes this ideal for full house renovations.

NOTE: Due to the weight of the Linear Double Radiators we recommend you install them onto solid walls.

RAL 9016 Max Working Pressure: 10 Bar 5 Year Guarantee
Product Code Height Width Depth Pipe Centers Wall to Face BTU's Watt's
LD606W 600 321 61 411 97 1476 432
LD608W 600 427 61 517 97 1967 576
LD610W 600 533 61 623 97 2459 720
LD612W 600 639 61 729 97 2951 864
LD614W 600 745 61 835 97 3443 1008
LD616W 600 851 61 941 97 3935 1152
LD618W 600 957 61 1047 97 4427 1296
LD620W 600 1063 61 1153 97 4918 1440
LD623W 600 1222 61 1312 97 5656 1656
LD627W 600 1434 61 1524 97 6640 1944
LD631W 600 1646 61 1736 97 7624 2232
LD635W 600 1858 61 1948 97 8607 2520
LD638W 600 2017 61 2107 97 9345 2736
  • Vertical Flat Panel Sections (Double Profile Sections)
  • A choice of 13 models to suit your needs from 1869 BTU (547 Watts) up to 11835 BTU (3466 Watts)
  • High quality gloss white powder coated finish
  • 5 year warranty
  • Built to last: 1.5mm thick mild steel for guaranteed quality
  • Tested to BS EN 442 Standards
  • ISO9001:2008 Registered Manufacturer
  • CE Marked

This is just a guide for reference only, rooms may require more than one radiator. If this applies to you, divide the required output between the number of radiators required. All figures given are for Delta T 50°
