Ultraheat "Planal" Flat Panel Horizontal White Radiator (Single Panel, Single Convector) - 59 Sizes

NWT2581-40906
Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
search
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)
  • Ultraheat "Planal" Flat Panel Horizontal White Radiator (59 Sizes - Single Panel, Single Convector)

An elegant radiator which utilises convected radiator heat to make this level of style affordable for every home. The Planal range of radiators contain a high output steel panel convector radiator surrounded by a stunning white cover.

Radiator Height:
Radiator Width:
£104.00
VAT included
local_shipping Order now for FREE delivery between Monday, 30th December - Tuesday, 31st December due to the Bank Holiday.

Data sheet

Outer Finish
White Powder Coating
Height (mm)
300mm, 400mm, 500mm, 600mm, 700mm, 900mm
Width (mm)
400mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 1100mm, 1200mm, 1400mm, 1600mm, 1800mm, 2000mm
Depth (mm)
52mm
Design
Planal
Colour Family
White
Material
Mild Steel
Output BTUs
888, 914, 1099, 1143, 1272, 1372, 1374, 1419, 1434, 1591, 1600, 1649, 1720, 1774, 1792, 1829, 1909, 1924, 2057, 2129, 2150, 2150, 2198, 2227, 2286, 2473, 2484, 2509, 2515, 2545, 2580, 2743, 2748, 2863, 2867, 3010, 3023, 3181, 3200, 3226, 3298, 3499, 3548, 3658, 3817, 3847, 3849, 3942, 4115, 4301, 4397, 4453, 4572, 4946, 5018, 5090, 5496, 5726, 6362
Fixing Kit
Wall Mounting Kit, Bleed Valve & Blank Plug Included
Guarantee
5 Years
Projection
70mm to 81mm
Pipe Centres
See Description
Socket Width
1/2" BSP
Pipe connection (mm)
15mm
Fuel Type
Central Heating
Brand
Ultraheat Ultraheat

An elegant radiator which utilises convected radiator heat to make this level of style affordable for every home. The Planal range of radiators contain a high output steel panel convector radiator surrounded by a stunning white cover.

300mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
300 500 500 260 888
300 800 800 415 1419
300 1000 1000 519 1774
300 1200 1200 623 2129
300 1400 1400 727 2484
300 2000 2000 1039 3548
400mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
400 400 400 268 914
400 500 500 335 1143
400 600 600 401 1372
400 700 700 468 1600
400 800 800 535 1829
400 900 900 602 2057
400 1000 1000 669 2286
400 1100 1100 736 2515
400 1200 1200 803 2743
400 1400 1400 937 3200
400 1600 1600 1070 3658
400 1800 1800 1204 4115
400 2000 2000 1338 4572
500mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
500 400 400 322 1099
500 500 500 402 1374
500 600 600 482 1649
500 700 700 563 1924
500 800 800 643 2198
500 900 900 724 2473
500 1000 1000 804 2748
500 1100 1100 884 3023
500 1200 1200 965 3298
500 1400 1400 1126 3847
500 1600 1600 1286 4397
500 1800 1800 1447 4946
500 2000 2000 1608 5496
600mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
600 400 400 372 1272
600 500 500 466 1591
600 600 600 559 1909
600 700 700 652 2227
600 800 800 745 2545
600 900 900 838 2863
600 1000 1000 931 3181
600 1100 1100 1024 3499
600 1200 1200 1117 3817
600 1400 1400 1303 4453
600 1600 1600 1490 5090
600 1800 1800 1676 5726
600 2000 2000 1862 6362
700mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
700 400 400 420 1434
700 500 500 525 1792
700 600 600 629 2150
700 700 700 734 2509
700 800 800 839 2867
700 900 900 944 3226
700 1000 1000 1049 384
700 1100 1100 1154 3942
700 1200 1200 1259 4301
700 1400 1400 1469 5018
900mm High - Single Panel - Single Convector
Height Width Pipe Centres Watts Btu's
900 400 400 503 1720
900 500 500 629 2150
900 600 600 755 2580
900 700 700 881 3010
  • Steel Single Panel Single Convector Radiators
  • A choice of 59 models to suit your needs from  888 BTU (260 Watts) up to 6362 BTU (1469 Watts)
  • High quality white coated finish
  • 5 year warranty
  • Built to last: 1.5mm thick mild steel for guaranteed quality
  • Tested to BS EN 442 Standards
  • ISO9001:2008 Registered Manufacturer
  • CE Marked
